Non-asbestos Beater sheet

Item: A.S.SEALS.4120

Description:

Specification:

CONSTRUCTION:

Asseals 4120 Non-asbestos beater sheet is made from synthetic emulsion, plants fiber and filling material. The production is used for position of lubrication system, which has the property of good compressibility and coefficient of resilience, in addition, the inside of gasket can properly swell to meet oil, that make up of the shortcoming that procession machining precision is not enough, which affected self-sealing.

Style 4120V is Vulcanized non-asbestos beater sheet with smooth faces.

PROPERTIES & APPLICATION:

Used in Automobile, farm machinery, motors, engineering etc. It can be used in oil system and water supply system at temperature 150¡æ

Item	Uint	4120	4120V
Density	g/cm	0.9~1.1	1.2~1.4
Tensile strength	¡ÝMpa	12.7
Compressibility	%	15¡À5
Recovery	¡Ý%	45
Stress relaxation	¡Ü%	35
Weight increase (in oil)	¡Ü%	35
Thickness increase (in oil)	¡Ü%	15

Normal color: Grey, Black, other color on request

Also available with anti-stick : 4120S, 4120VS

or graphite coating: 4120G, 4120VG

THICKNESS TOLERANCE:

Item	Tolerance	In same sheet
Thickness	¡Àmm	mm
0.5	0.05	0.06
0.6-0.8	0.06	0.08
1-2	0.08	0.08

FORMS OF SUPPLY:

Sheets

Width: 500mm; 1000mm

Length: 500mm; 1000mm; 1200; 1500mm

Thickness: 0.3~2.0mm
