Graphite packing with carbon fiber corners

Item: A.S.SEALS.2010

Description: Diagonally braided from expanded flexible graphite, reinforced at the corners throughout with high quality carbon fiber. This corners and body make it three times more resistant to extrusion and also increase the pressure handing capabilities compared to 2000.

Specification:

Diagonally braided from expanded flexible graphite, reinforced at the corners throughout with high quality carbon fiber. This corners and body make it three times more resistant to extrusion and also increase the pressure handing capabilities compared to 2000.

APPLICATIONG:

Can be used in many demanding applications, both dynamic and static. Particularly suited for high temperature and high pressure service in valves, pumps, expansion joints, mixers and agitators of pulp and paper, power station and chemical plant etc.

SERVICE LIMITS:

Style		2010
Temperature		-200~+550 0C
Pressure Shaft speed	Rotating	25 bar-20m/s
	Reciprocating	100 bar-2m/s
	Valve	300 bar-2m/s
PH Range		0~14
Density(appr.)		1.0~1.3g/cm3

FORMS OF SUPPLY:

in coils of 1 to 5 kg, other package on request.

as packing rings--- R2010

as precut length
