Graphite packing with (G)PTFE corners
Graphite packing with (G)PTFE corners
Item: A.S.SEALS.2030
Description:
Send Inquiry Now! Live Chat Now!

Specification:

Asseals 2030 Graphite packing with PTFE corners

PTFE corners effectively prevent graphite extrusion, this packing contains the advantage of PTFE and graphite. Graphited PTFE corner is also efficient.

APPLICATIONG:


Can be used in many demanding applications, both dynamic and static. Particularly suited for high temperature and high pressure service in valves, pumps, expansion joints, mixers and agitators of pulp and paper, power station and chemical plant etc.

SERVICE LIMITS:


Style
2030
Temperature
+280¡ãC
Pressure
Shaft speed
Rotating
25 bar-25m/s
Reciprocating
100 bar-2m/s
Valve
300 bar-2m/s
PH Range
0~14
Density(appr.)
1.3~1.5 g/cm3

FORMS OF SUPPLY:

in coils of 1 to 5 kg, other package on request.
                                      as packing rings--- R2030 etc.
                                      as pre cut length
