Graphite packing reinforced with Inconel wire & mesh wrapped
Graphite packing reinforced with Inconel wire & mesh wrapped
Item: A.S.SEALS.2000M
Description:
Send Inquiry Now! Live Chat Now!

Specification:
Asseals 2000M
Graphite packing reinforced with nickel wire & mesh wrapped

CONSTRUCTION

2000M¡ªSuper-high Temperature & Pressure Valve Packing, is braided from low-sulphur expanded graphite yarns with corrosion inhibitor, reinforced with Inconel wire. Each yarn is round braided with Inconel mesh again.

APPLICATION :
Super-high Temperature & Pressure Valve Packing , The exclusive packing is formable, yet tough. Rated in steam service 500bar, maintains integrity in steam up to 650¡ãC. It is a cost-effective as well as a confident choice.
PROPERTIES :
Service Limits
T
-200~+650 ¡æ
PH
0-14
V
2m/s
P
Rotating
----
Reciprocating
----
Valve
500bar
D(g/cm3)
1.1-1.4
FORMS OF SUPPLY:
2-5 kgs/roll
Packing Ring: R2000M
As customer¡¯s requirements.
