Acid-resisting Asbestos rubber sheet
Acid-resisting Asbestos rubber sheet
Item: A.S.SEALS.AIFLON
Description:
Send Inquiry Now! Live Chat Now!

Specification:
Asseals Acid-resisting ACAF is made of good asbestos fiber with acid-resisting synthetic rubber compression heating and compression molding it.

APPLICATION:
Mainly used for the equipment in acid, and used as sealing materials of gaskets for the flange of pipeline joints.
PROPERTIES:


     Item                        Style

3235
3225
3220
Horizontal Strain MPa¡Ý
14
11
8
Weight-increasing
96.17%( H2SO4) =18mol/L*48h
¡Ü30%
¡Ü30%
¡Ü30%
36.97%(HCL)=12mol/L*48h
¡Ü25%
¡Ü25%
¡Ü25%
10% (HNO3)= 1.67mol/L*48h
¡Ü20%
¡Ü20%
¡Ü20%
Max. Pressure  Mpa
4.0
2.5
2.0
Max. Temperature ¡æ
350
250
200
Strain-decreasing %¡Ü
50
Aging Coefficient
0.9
Softness
No Crack
Density g/cm 2
1.8-2.0
Burning Loss %
30
Compressibility
12¡À5
Elasticity¡Ý%
40


FORMS OF SUPPLY:

Sheets£º
1500¡Á4000mm, 1500¡Á2000mm
1500¡Á1350mm, 1500¡Á1000mm
1270¡Á3810mm, 1270¡Á1270mm
Thickness:  0.4~6mm

Cut gaskets£º
ACAF G3220, G3225, G3235
Dimensions according to drawings or specifications and standards
